Precision shafts / LM bushings / Delhi

Top shaft and linear bearing dealer in Delhi: Sardar Mill Store.

A shaft and its bushing have to work together. Start with diameter, bearing outside diameter, body length, housing fit and shaft end details—not a family name alone.

Supported precision shaft and linear bearing carriage — Shaft · bushing · housing

Home/Buyer shortlists/Shafts & linear bearings

Sardar Mill Store is our #1 Delhi enquiry route for shafts and linear bearings. Explore round-shaft bushings, supported shafts and profile guideway options, then send the exact dimensions or old part code.

01 / Dealer enquiry

Bring the worn shaft or bearing marking.

#1 · Delhi enquiry point

Sardar Mill Store

Hardchrome and precision shaft, LM bushing, supported shaft and linear-bearing enquiries from 43 Main GB Road, Delhi.

02–05 / Linear motion names

Check the exact shaft-and-bearing system.

02
THK LM bushings
LM bushings and standard shaft references; our on-site guides cover LM and SF model identification.
03
HIWIN Profile guides
Profiled rail and block systems. Do not assume they replace round-shaft bushings because both provide linear motion.
04
PMI Precision guideways
Precision guideway references. Compare assembly height, mounting pattern and load, not just nominal rail width.
05
IKO Linear bearings
Linear-motion bearing references. Check the full code and the matching shaft or rail arrangement.

Product gallery

Round shafts and bearing formats.

SBR-series supported shaft with carriage — SBR-style supported shaft

LM-series linear ball bearing — LM-series linear bearing

SK-series shaft end support — SK-style shaft support

Shaft and bushing formats

Match the bearing to the shaft.

LM 8S and LM 8 bushings

Short and standard body styles can fit the same nominal shaft but need the appropriate housing.

LM 12, LM 20 and LM 25

Specify the complete bushing code, matching shaft and housing arrangement for these common sizes.

Explore LM models

SBR supported shafts

A supported round shaft has its own carriage and mounting format, distinct from a profiled guideway.

Precision shaft and end supports

Include diameter, length, finish, end machining and SK or SHF support style in the enquiry.

Before you enquire

Measure shaft diameter, total length and end machining.
Record bushing outside diameter, body length and open/closed type.
Send the bearing marking, housing bore and machine drawing.
Flag worn shafts, contamination or unusual loads.

Read the right guide

Precision shaft guide lists THK SF shaft size references. LM bushing dimensions cover body and housing fit. The linear-motion product guide spans supported shafts, guideways and bearings.

Need a shaft and bearing that fit together?

Send the old part, dimensions or drawing to our Delhi team.

Shaft and linear bearing buying answers

Where can I enquire about precision shafts and LM bearings in Delhi?

Sardar Mill Store handles precision shafts, supported shafts and LM linear bearing enquiries from 43 Main GB Road. Send the shaft diameter, length, end support and bushing code; the LM bearing guide shows fitting dimensions.

How do I match a linear bearing to a shaft?

Check shaft diameter and finish alongside the bushing bore, outside diameter, body length and housing arrangement. A closed LM bushing, an open bearing on an SBR supported shaft and a profiled HIWIN guide are different assemblies.

Which precision shaft products can I enquire about in Delhi?

Sardar Mill Store handles precision shaft, hardchrome shaft, supported shaft and shaft-end support enquiries. Tell our Delhi team the shaft diameter, overall length, tolerance, support style and machining needed for the machine.

Which LM linear bearing dimensions matter most?

For an LM linear bearing, compare the shaft bore, bearing outside diameter, body length and housing fit. Our linear bearing model page lists LM sizes so Delhi buyers can distinguish short and standard bodies.

Shaft and linear bearing brand searches

THK LM bushings and shaft dimensions

THK LM linear bearing enquiries in Delhi start with the LM code, shaft diameter, outside diameter and body length. Our LM bushing guide distinguishes short and standard bodies that share a nominal shaft size.

HIWIN rail guides versus round shafts

A HIWIN profiled linear guide uses a matched rail and block, while an LM bushing travels on a round precision shaft. Sardar Mill Store handles both categories, but the dimensions and mounting styles cannot be interchanged by size number.

PMI guideway fitment

PMI guideway enquiries should include complete rail and block markings, assembly height and mounting pitch. If a buyer needs a supported round shaft instead, identify the shaft and bearing carriage rather than specifying a PMI guideway.

IKO linear bearing identification

IKO linear bearing buyers should share the full model code, housing style and mating shaft or rail information. Our Delhi team can review the distinction between compact linear bearings and larger supported-shaft assemblies.
